Name: AMD Series
Brand: AIRBEST (CHANGXING) TECHNOLOGY CO., LTD.

Features

 

Large Flow Vacuum Generator

Built-in vacuum cartridge, greatly improve the energy consumption ratio
Suitable connection specifications can be configured according to different vacuum flow requirements
Various connection specifications can meet different requirements

Selection Guide

 

AMD SERIES MULTISTAGE VACUUM GENERATOR

AMD - S 3 - LG8 - G8

① ② ③ ④ ⑤

① Series	② Performance	③ Specification	④ Connection plate specification	⑤ Vacuum port specification
AMD	X - High vacuum level	1	LG8 - Straight exhaust, Air supply port: G1/4	G8 - Vacuum port G1
	S - Large vacuum flow	2	Vacuum detecting port: G1/8，	G6 - Vacuum port G3/4
		3	Exhaust detecting port: G1
		4	LG6 - Side exhaust, Air supply port: G1/4
			Vacuum detecting port: G1/8，
			Exhaust port: G3/4

Technical parameters

Model	Air supply pressure range bar	Working temperature ℃	Rated air supply pressure bar	Max. vacuum level -kPa	Max. vacuum flow NL/min	Air consumption NL/min	Noise level dB(A)	Recommendedhosedia. mm (Hose outer dia.) Air supply port	Recommendedhosedia. mm (Wired hose inner dia.) vacuum port V
AMD-X1	4.0~7.0	-10~80	5	5	354	130	63~72	≥φ8	≥φ25
AMD-X2	4.0~7.0	-10~80	5	5	700	260	63~72	≥φ8	≥φ25
AMD-X3	4.0~7.0	-10~80	5	5	980	390	63~72	≥φ10	≥φ45
AMD-X4	4.0~7.0	-10~80	5	5	1,380	520	63~72	≥φ10	≥φ45
AMD-S1	4.0~7.0	-10~80	6	6	360	135	63~72	≥φ8	≥φ32
AMD-S2	4.0~7.0	-10~80	6	6	710	270	63~72	≥φ8	≥φ32
AMD-S3	4.0~7.0	-10~80	6	6	1,050	405	63~72	≥φ10	≥φ45
AMD-S4	4.0~7.0	-10~80	6	6	1,410	540	63~72	≥φ10	≥φ45
