Universal Mounting Parts-Ball Joint

Universal Mounting Parts-Ball Joint

PJB Series
Contact Us download
Products

Features Features

Universal Mounting Parts-Ball Joint
Universal Mounting Parts-Ball Joint

  • Flexible connection for deflection in any direction with a maximum deflection angle of 12°


  • The ball and socket are equipped with sealing rings to prevent vacuum leakage during rotation


  • It is made of high strength steel and has good stability


  • Suitable for large suction cup to handle workpiece with an inclined surface

Selection Guide Selection Guide

PJB Series Mounting Parts

PJB - G4M - S

  ①      ②     ③


① Series② Suction cup connection③ External sealing device
PJBG1M - G1/8 male thread              G2M - G1/4 male threadNil - Standard type
M10M - M10×1.25 male thread    G4M - G1/2 male threadS - With an external sealing suction cup


Selection


Model/Suction cup connection
G1MM10MG2MG4M
PJB-G1M PJB-G1M-SPJB-M10MPJB-G2MPJB-G4M PJB-G4M-S



Dimensions Dimensions

Universal Mounting Parts-Ball Joint

Dimensions PJB Series Universal Mounting Parts-Ball Joint

Model/SizeHG1L1G2L2SdDeflection
angle		Weight
g
PJB-G1M26.5G1/88G1/8712212°20
PJB-M10M37.5G1/412M10×1.2510193.512°82
PJB-G2M37.5G1/412G1/410193.512°75
PJB-G4M40G1/215G1/21224412°113

Dimensions PJB Series Universal Mounting Parts-Ball Joint PJB-S


Model/SizeHG1L1G2L2SDeflection
angle		Weight
g
PJB-G1M-S33G1/88G1/871212°21
PJB-G4M-S52G1/215G1/2122412°133
